Description of the engines:
Certificate of Airworthiness is valid until 20.09.2024
Engines: 2 x GE H80-200
TTSN: 2356/3119
Remained TBO: 1244/481
Propellers: 2 x AV725
TTSN: 3731/3691
Remained TBO: 3569/3569
Avionics:
Radio-navigation equipment
Electronic information system EFI-890R 2 sets
Attitude heading reference
system
AHS-1000A 2sets
Digital air data computer AC32.10.21.11.AF 2 sets
NAV/COM/GPS GNS 430 (W) 2 sets
Marker beacon receiver KMR 675 1 set
Automatic direction-finding
equipment KR 87 2 sets
Distance measuring equipment KDM 706A 1 set
Intercom and passenger
announcing system
KMA 24 H-70 2 sets
Radar beacon transponder I MST 67A 1 set
Radar beacon transponder II GTX 330 D 1 set
Flight data recorder FA-2200 1 set
Emergency beacon ELT C406-2 1 set
Pilot cab sound recorder FA-2100 1 set
Weather radar RDR-2000 1 set
Height finder KRA 405B 1 set
EGPWS MARK VI 1 set
Portable emergency beacon ARM-406AS1 1 set
Autopilot KFC 325 1 set
Traffic collision avoidance
system
TCAS II Preparation for installation
Equipment:
Instrumentation system
Speed indicator Thommen 5A-16 or LUN 1106.K5Bx 1 set
Barometric pressure
altimeter
3A62 1 set
Secondary horizon
indicator
MCI 4300-412 or LUN 1241.D8D5R 1 set
Magnet compass 5LUN 1224-8 1 set
Torque indicator LUN 1539.02-8 2 sets
Core engine RPM
indicator
LUN 1347.83-8 2 sets
Propeller RPM
indicator
LUN 1348.03-8 2 sets
Temperature indicator LUN 1370.08-8 2 sets
Three-pointer engine
gage unit
LUN 1538.01-8 2 sets
Main fuel tank level
indicator
LUN 1634.01-8 2 sets
Tip tanks fuel level
indicator
LUN 1674-8 2 sets
Rate meter PC 900-1 2 sets
Double pointer air
Thermometer
LUN 5610.01-8 1 set
Time meter 115EG-7780 2 sets
Exterior:
Exterior service labels:
For maintenance - English
For passengers - Russian
Interior:
19/17/15 passenger seats with headrests, without tables, fabric
seat upholstery. Rear luggage compartment 215 kg or 330 kg. Enhanced lavatory
Modifications/changes:
No modifications
Status of the inspection:'
LIST OF EQUIPMENT WITH MINIMAL RESIDUAL LIFE REMAINED
1 RPM indicator 4800hrs/10yrs
LUN 1347.93-8
1 41 hrs including 5%
prolongation
2 Solenoid air valve 7 yrs LUN 2477.01.-8
1 Until 24.10.21
3 Solenoid air valve 7 yrs LUN 2477.02.-8
1 Until 24.10.21
4 Fuel filter pressure
alarm
3000hrs/10yrs
LUN 1493.04 1 128 hrs including 5%
prolongation
5 Voltage regulator 3075hrs/7yrs
LUN 2167.03-8
2 64 hrs ; 202 hrs
6 Main landing gear
cylinder
6000hrs/7yrs
LUN 7108.11-7;.
7108.12-7
2 Until 09.09.21г. 4
months
7 Front landing gear
cylinder
6000hrs/7yrs
LUN 7233.04-7 1 Until 09.09.21г. 4
months
Other comments:
CoA is valid until 20.09.2024
SUPPORTING DOCUMENTATION (originals in English with translation into Russian):
TECHNICAL DOCUMENTATION
1. Aircraft logbook 1 pc.
2. Engine logbook 2 pcs.
3. Propeller logbook 2 pcs.
4. Passports and Certificates for aggregates/devices 5 sets
5. Hose book 1 pc.
6. Aircraft leveling protocol 1 set
7. Aircraft weight and balance protocol 1 set
8. Protocols of calibration of flight data recording 1 set
9. System check protocol EFI-890R 1 set
10. Calibration report for spare altimeter 1
11. Protocol of the final test flight 1 set
12. Passenger safety instructions 1 set
OPERATIONAL DOCUMENTATION
1. Flight manual of the aircraft L 410 UVP E-20 (Do-L410-1218.2) 1 book.
Translation: Aircraft Flight Manual
L 410 UVP-E20 1 book
2. Checklist for emergency, abnormal and normal procedures.
L 410 UVP - E20 1 book
Translation: List of emergency action checklists,
abnormal and normal situations L 410 UVP-E20 1 book
3. Master minimum Equipment List L 410 UVP-E, E9, E20
(Do-L410-3000.2) 1 CD
Translation: The main list of minimal
equipment for L 410 UVP-E20 1 CD
4. Operation manual for the aircraft L 410 UVP-E, E9, E20.
(Do-L410-1232.2) 1 CD
Translation: Technical Operation Manual
aircraft L 410 UVP-E20 7 books
5. Maintenance schedule for L 410 UVP-E20.
without overhaul (Do-L410-1223.2) 1 CD
Translation: Maintenance regulations L 410 UVP-E20 1 book
6. Inspection manual for L 410 UVP-E, E9, E20 (Do-L410-2011.2) 1 CD
Translation: A Guide to Preventive Technical maintenance of the aircraft L 410 UVP-E 1 book
7. Wiring manual for L 410 UVP-E, E9, E20.
(Do-L410-1242.2) 1 CD
Translation: Album of wiring diagrams of aircraft L 410 UVP-E20 2 books
8. AV-725 (EN-1320) Operation and Installation Manual 1 CD
Translation: Maintenance and Operation Manual propeller AV725
9. Maintenance manual for the turboprop engine model GE H80-200.
(No. 0983402) 1 CD
Translation: Technical Operation Manual.
turboprop engine GE H80-200 (No. 0983402)
10. Ground and flight checks L 410 UVP-E, E9, E20 1 book.
Translation: Maps of control checks at the aerodrome and in flight 1 book
11. Illustrated catalog of spare parts for the aircraft L 410 UVP-E20.
(Illustrated spare parts catalog for L 410 UVP-E20) 1 CD
12. Repair manual L 410 UVP-E20 on 1 CD.
Translation: Repairs manual for airframe of the aircraft L 410
in field 1 book
13. List of compulsory bulletins performed.
Translation: List of completed revisions according to mandatory
ballots 1 set
14. Program for decoding flight data "ROSE" 1 CD
