Описание двигателей:
Rotax 912 with 100hp, autogyro ELA 09 JUNIOR, manufacturer Spain Ela Aviation
Авионика:
standart
Оборудование:
Rotor aluminium rotor blades is Averso, 8,50 m, fuel tank 45 litres
Экстерьер:
according model, looks like new
Интерьер:
COUNTRY OF ORIGIN:
Spain
DESCRIPTION:
Two-seat light sport gyroplane
POWER PLANT:
One 75 kw (100 hp) Rotax 912ULS four-cylinder horizontally-opposed liquid-and-air-cooled engine
SPECIFICATIONS:
Rotor diameter: 8.25 m (27 ft)
Never exceed speed: 150 km/h (95 mph)
Cruising speed: 100 to 120 km/h (60 to 75 mph)
Fuel capacity: 45 litres (10 Imp gals)
Endurance: 2.5 hour
Range: 250 km (155 miles)
Take-off distance: 100 m (330 ft)
Landing distance: 0 to 20 m (0 to 65 ft)
Empty weight: 245 kg (540 lb)
Useful load: 205 kg (450 lb)
Loaded: weight 450 kg (992 lb)
Модификации / изменения:
ELA 09 JUNIOR
DESCRIPTION
Without filters. Which means that nothing gets in the way between you and the world. Every one of the outer details gets you closer to the authentic flight experience. Renouncing to all that is superfluous. With clearly defined forms that obey above all to functionality. The result: a design perfected by the multiple challenges in the past, and with the relentless effort of our designers and bodywork masters.
No heating. No excess of instruments. No distractions. Should you miss something? Absolutely not. Every pound that we eliminated from the 09-Junior impacts its performance.
Ultra-short take-offs, wide speed range, from 35 km/h (21.74 mph) to 120 km/h (74.5 mph) of continuous cruise and with a maximum speed of 150 km/h (93.2 mph).
Состояние осмотра:
General characteristics
Crew: one
Capacity: one passenger
Empty weight: 240 kg (529 lb)
Gross weight: 450 kg (992 lb)
Fuel capacity: 45 litres (9.9 imp gal; 12 US gal)
Powerplant: 1 × Rotax 912 ULS four cylinder, liquid and air-cooled, four stroke aircraft engine, 75 kW (100 hp)
Main rotor diameter: 8.25 m (27 ft 1 in)
Main rotor area: 53 m2 (570 sq ft)
Propellers: 3-bladed composite
Performance
Maximum speed: 150 km/h (93 mph, 81 kn)
Cruise speed: 120 km/h (75 mph, 65 kn)
Rate of climb: 3.5 m/s (690 ft/min)
Disk loading: 8.5 kg/m2 (1.7 lb/sq ft)
Другие комментарии:
2020 flight certificate
